Specifications
| Self-Levelling Feature | |
|---|---|
| Self-Levelling | Mechanical |
| Tractor Compatibility | |
|---|---|
| Matching Tractor Model Or Series, First | Magnum 250-380 |
| Lift Capacities | |
|---|---|
| Lift Capacity To Maximum Height, At Pivot Pin (lb) | 6867 |
| Lift Capacity To Max. Height, 800mm (31.5in) Forward Of Pivot Pin (lb) | 6504 |
| Lift Capacity To 1.5m (59in) at Pivot Pin (lb) | 8532 |
| Lift Capacity To 1.5m (59in) Height, 800mm (31.5in) Forward Of Pivot Pin (lb) | 7822 |
| Lift Height Dimensions, Fully Raised | |
|---|---|
| Max Lift Height To Bucket Pivot Pin (in) | 195 |
| Max Lift Height Under Level Bucket (in) | 183 |
| Max Dump Clearance (in) | 156 |
| Boom Lift Breakout Force | |
|---|---|
| Boom Breakout Force, At Pivot Pin, Bucket At Ground (lbf) | 9987 |
| Boom Breakout Force, 800mm (31.5in) Forward Of Pivot Pin At Ground (lbf) | 8554 |
| Bucket Rollback Force | |
|---|---|
| Bucket Rollback Force At Max. Height, 800mm (31.5in) Forward Of Pivot Pin (lbf) | 7915 |
| Bucket Rollback Force At Ground, 800mm (31.5in) Forward Of Pivot Pin (lbf) | 10560 |
| Horizontal Reach Distance | |
|---|---|
| Dump Reach At Maximum Lift Height (in) | 44 |
| Ground Level Reach (in) | 123 |
| Dump And Rollback Angles | |
|---|---|
| Max Dump Angle, Loader Raised (°) | 50 |
| Max Rollback Angle, Bucket At Ground (°) | 42 |
| Digging Depth | |
|---|---|
| Digging Depth (in) | 7.9 |
| Couplers For Buckets And Attachments | |
|---|---|
| First Coupler Type Available | Euro style |
| Hydraulic Function, Ride And Detachable Features | |
|---|---|
| Third Function Valve Available | Optional |
