Features
Specifications
| Self-Levelling Feature | |
|---|---|
| Self-Levelling | Mechanical |
| Tractor Compatibility | |
|---|---|
| Matching Tractor Model Or Series, First | Farmall 90C, 100C, 110C, 120C |
| Lift Capacities | |
|---|---|
| Lift Capacity To Maximum Height, At Pivot Pin (lb) | 2690 |
| Lift Capacity To Max. Height, 800mm (31.5in) Forward Of Pivot Pin (lb) | 3240 |
| Lift Capacity To 1.5m (59in) at Pivot Pin (lb) | 3290 |
| Lift Capacity To 1.5m (59in) Height, 800mm (31.5in) Forward Of Pivot Pin (lb) | 3330 |
| Lift Height Dimensions, Fully Raised | |
|---|---|
| Max Lift Height To Bucket Pivot Pin (in) | 135 |
| Max Lift Height Under Level Bucket (in) | 124 |
| Max Dump Clearance (in) | 100 |
| Boom Lift Breakout Force | |
|---|---|
| Boom Breakout Force, At Pivot Pin, Bucket At Ground (lbf) | 4180 |
| Boom Breakout Force, 800mm (31.5in) Forward Of Pivot Pin At Ground (lbf) | 3550 |
| Bucket Rollback Force | |
|---|---|
| Bucket Rollback Force At Max. Height, 800mm (31.5in) Forward Of Pivot Pin (lbf) | 3060 |
| Bucket Rollback Force At Ground, 800mm (31.5in) Forward Of Pivot Pin (lbf) | 4055 |
| Horizontal Reach Distance | |
|---|---|
| Dump Reach At Maximum Lift Height (in) | 35 |
| Ground Level Reach (in) | 86 |
| Dump And Rollback Angles | |
|---|---|
| Max Dump Angle, Loader Raised (°) | 52 |
| Max Rollback Angle, Bucket At Ground (°) | 41 |
| Digging Depth | |
|---|---|
| Digging Depth (in) | 6.3 |
| Couplers For Buckets And Attachments | |
|---|---|
| First Coupler Type Available | Skid-steer style |
| Hydraulic Function, Ride And Detachable Features | |
|---|---|
| Third Function Valve Available | Dealer install |
