Features
New For Model Year 2024
Extra Lift Capacity for Heavier 3-point Hitch-mounted Implements
For operators needing extra lift capacity, this high-capacity hitch is available on the Farmall 140A. With larger assist cylinders combined with extra weight on the front of the tractor, this hitch option increases tractor lift capacity to approximately 10,000 lbs. Designed for producers using heavy planters or transplanting implements in specialty operations.
Combine the Farmall’s maneuverability and smaller footprint with greater lift capacity for even more flexibility in your operation.
Engine
All the Horsepower You Need with No Regeneration
Equipped with a 4-cylinder 4.5 liter FPT engine, these electronically-controlled and Tier 4 B/Final compliant engines provide faster throttle response, improved cold weather starting, increased fuel efficiency, and quieter operation. Unlike some competitive utility tractors, Farmall 100A series tractors do not have a diesel particulate filter, avoiding downtime and increasing productivity with no regeneration.
Transmission
Smooth Shifting Options to Match Your Needs
Choose from three transmission options to best suit your operation:
- 8×8 power shuttle (standard)
- 8×8 Synchro mechanical option with mechanical reverser
- 16×8 power shuttle
Operator Environment
Comforts to Make Long Days Seem Shorter
Hundreds of hours of research go into making long days seem shorter, controls seem more natural and chores seem less challenging in Case IH equipment. Farmall large utility 100A series tractors continue the long-standing Farmall commitment, putting a high priority on operator comfort and productivity.
Comfort
- Climate-controlled to keep the elements out
- Contoured seat comes standard with the Farmall 100A and an optional air suspension seat is available with 15 degree swivel
Convenience
- Integrated loader joystick comes standard from the factory and is integrated into the right-hand console for easier operation and greater productivity
- Two-door entry provides easy access
Visibility
- Curved window frame increases loader visibility and provides outstanding overall visibility at a lower base investment
- Optional high visibility roof panel allows the operator to see full-range loader operation while the sloped hood provides superior forward visibility
Hydraulics and Hitches
Lift Heavy Loads with Confidence
Farmall large utility 100A series tractors come equipped with a three-point hitch with a lift capacity of 7,200 pounds. Plus, the 22 GPM hydraulic flow capacity allows you to lift heavy loads with ease.
Connect implements quickly and easily with two standard-equipment, deluxe remotes with flow control and breakaway couplers. Easily add two more remotes as needed.
Maintenance and Uptime
Maximize Your Time Behind The Wheel
Farmall large utility 100A series tractors are engineered with rugged Case IH components proven to provide years of reliable service. Case IH quality replacement parts, maintenance programs and service expertise are designed to boost equipment efficiency and protect your investment – season after season.
Maximize Your Time Behind The Wheel
Farmall large utility 100A series tractors are engineered with rugged Case IH components proven to provide years of reliable service. Case IH quality replacement parts, maintenance programs and service expertise are designed to boost equipment efficiency and protect your investment – season after season.
Specifications
Classification Horsepower | 110 |
Drive Type | Wheeled Tractor |
Drive Configuration | 4WD |
Application | Utility Tractor |
Rated Engine Power hp | 110 |
Rated Speed rpm | 2200 |
Fuel Tank gallon (US) | 56.8 |
DEF Tank gallon (US) | 7.9 |
Motor Performance | |
Traction Battery | |
Rear PTO | |
PTO Power hp | 92 |
540rpm | |
540 Available? | Yes |
1000rpm | |
1000 Available? | Yes |
Front PTO | |
Details | |
Make | FPT |
Cylinders | 4 |
Displacement in³ | 275 |
Aspiration | Turbocharger. Aftercooler |
Fuel System | |
Emission Treatment | |
Exhaust Gas Recirculation | Yes |
Diesel Oxidation Catalyst | Yes |
Selective Catalytic Reduction (SCR) | Yes |
Exhaust Orientation | Vertical |
System Rating V | 12 |
Alternator | |
Voltage V | 12 |
Rating A | 120 |
Engine Battery | |
Description | Power Shuttle w/ Hi-Low |
Type | Power Shuttle |
Forward Speeds | 16 |
Reverse Speeds | 8 |
Steering Configuration | Front Steer |
Axle Output | Bar or flange |
System Type | Open Centre / CCLS |
Main Pump Type | Fixed Displacement Pump |
Implement Pump Flow gallon (US)/min | 22 |
Remote Valves | 2 - 4 |
Hydraulic Tank Capacity gallon (US) | 16 |
Features | |
3-Point Hitch Category | Category 2 |
Draft Sensing Or Lift Control | Top link sensing |
Draft Link Ends Telescopic | Standard |
Lift Capacity | |
Standard Capacity 24 Inches Behind Pin lb | 7200 |
Wheelbase in | 103.9 |
Length in | 184.7 |
Height Over Cab in | 110.2 |
Weight lb | 10538 |
Rear Tire Size | 18.4 R38 |
Tracks |
