Features
Cutterbar
Durable and Versatile Cutterbar
The DC3 series disc mower conditioners have a cutterbar designed for durability and maximized profit. Featuring a modular design, simplified drive system, quick-change knives and counter-rotating discs and a 3-Year Warranty.
Cutterbar Access
Easy Access to the Cutterbar for More Productivty
Conditioners
Best-in-Class Conditioning
The wider conditioners on the Case IH Disc Mower Conditioner series allows for a thinner crop mat, leading to uniform conditioning and greater sun exposure for faster dry down. The torsion-bar roll-pressure design applies equal force to the conditioning rolls for greater consistency, with an almost 1-to-1 cut width to conditioner ratio on DC103 and DC135 models. The innovative Case IH flail system removes the waxy outer layer for faster dry-down in grass.
No-Tool Adjustments
Make Adjustments in the Field
Several systems on the disc mower conditioners can be adjusted without tools, letting you get into the field faster.
- Windrow Formation - Swathgate, swathgate fins and forming shields are easily adjusted without tools. Spread wide or narrow to fit your needs
- Conditioning Roll Pressure - A single point of adjustment fine tunes the roll pressure
- Knife Maintenance - The provided tool allows you to change the quick-change knives in seconds
- Cutting Height - Repositioning a pin in the hydraulic tilt cylinder changes the cutting height
Hitches
Maximum Turning Performance
Warranty
Peace of Mind Comes Standard
To provide our customers with peace of mind during hay season DC3 and DC5 series mower conditioners will now come with a two-year base warranty. From the hitch to the rear axle, we want our customers to know that we’ve got their backs.
Specifications
Tongue Type | Side-Pull, curved tongue |
Cutting Width ft-in | 11ft 7in |
Cutter Bar Tilt Angle ° | 2 |
Cutter Bar Lubrication | Sealed independent disc modules |
Number Of Discs | 7 |
Number Of Knives Per Disc | 2 |
Disc Speed rpm | 2250 |
Disc Drive Components | Shafts w/bevel gears |
Flotation | Up & back, adjustable springs |
Conditioner Type | Rolls |
Conditioner Drive | 4 HB V-belt & enclosed gears |
Roll Length in | 102 |
Roll Diameter in | 10.4 |
Roll Speed rpm | 750 |
Roll Material | Rubber |
Optional Roll Material | Steel |
Roll Surface Pattern | Chevron intermeshing |
Min PTO Power Required hp | 80 |
PTO Rated Speed rpm | 540 |
Hookup To Tractor Drawbar | Category 2 / 3 |
Hookup To Tractor Hitch Lift Arms | Swivel hitch option |
Tractor Hitch Size | Category 3 |
Hydraulic Relief Pressure psi | 1500 |
Transport Width ft-in | 11ft 7in |
Transport Length ft-in | 27ft 5in |
Transport Height ft-in | 7ft 5in |
Ground Clearance in | 16.2 |
Weight With Roll Conditioner lb | 5880 |
Tire Size | 12.5L-15.8 |
